5P3B25-AAIBAEAFAAEA1K4AA1+LA – Cảm biến đo lưu lượng – E+H – Song Thành Công
Tên: 5P3B25-AAIBAEAFAAEA1K4AA1+LA – Cảm biến đo lưu lượng
Model: 5P3B25-AAIBAEAFAAEA1K4AA1+LA
Nhà sản xuất: E+H
Đại lý phân phối: Song Thành Công
Thông tin sản phẩm:
Xem thêm thông tin sản phẩm tại đây
- Nominal diameter range
- DN 15 to 600 (½ to 24″)
- Wetted materials
- Liner: PFA; PTFE
Electrodes: 1.4435 (F316L); Alloy C22, 2.4602 (UNS N06022); Tantalum; Platinum; Titanium - Measured variables
- Volume flow, conductivity, mass flow
- measurement error
- Volume flow (standard): ±0.5 % o.r.± 1 mm/s (0.04 in/s)
Volume flow (option): ±0.2 % o.r. ± 2 mm/s (0.08 in/s) - Measuring range
- 4 dm³/min to 9600 m³/h (1 gal/min to 44 000 gal/min)
-
process pressure
- PN 40, Class 300, 20K
- Medium temperature range
- Liner material PFA: –20 to +150 °C (–4 to +302 °F)
Liner material PFA high-temperature: –20 to +180 °C (–4 to +356 °F)
Liner material PTFE: –40 to +130 °C (–40 to +266 °F) - Ambient temperature range
- Flange material carbon steel: –10 to +60 °C (+14 to +140 °F)
Flange material stainless steel: –40 to +60 °C (–40 to +140 °F) - Sensor housing material
- DN 15 to 300 (½ to 12″”): AlSi10Mg, coated
DN 350 to 600 (14 to 24″”): Carbon steel with protective varnish - Transmitter housing material
- AlSi10Mg, coated; 1.4409 (CF3M) similar to 316L; stainless steel for hygenic transmitter design
- Degree of protection
- Standard: IP66/67, Type 4X enclosure
Các model sản phẩm:
| (Raytek) Fluke Process Instrument | Item no: 2475424 Part no: XXXSYSECPI Position indicator Accessories for MP150 |
| AKAPP | Model: C91A Akapp Carbon Brush, Earth. |
| Appleton | P/N: 0BVA JBEP Series FRP Terminal Junction boxes for Electrical/Power Applications 4xM20 with earth continuity sheet |
| Appleton | P/N: VAD-1M Adapter/Socket |
| Appleton | P/N: VPX75 Mounting Hoods Ceiling |
| Appleton | P/N: VGL-1RE Glass Globes — 60-150 W red HÀNG DỄ VỠ |
Appleton |
P/N: VPGL-1RE RED GLASS GLOBE HÀNG DỄ VỠ |
| Appleton | P/N: VWG-1 60-150W STEEL WIRE GUARD |
| Appleton | P/N: VPGU-1 WIRE GUARD |
| Assalub | 0102095 Grease pump |
| Bently Nevada | Model: 330130-080-00-00 Standard Extension Cable |
| Burkert | Code: 50294 Description: 2/2-way-valve |
Burkert |
Code: 140564 Description: 2/2-way-valve |
| BURLING INSTRUMENTS | B1C62N1632000 SET @ 265F Temperature Control |
| BURLING INSTRUMENTS | B1C62N1632000 SET @ 265F Temperature Control |
| CCS | Correct Model: 604PM21 Pressure switches |
| CCS | Correct Model: 604GM3 Pressure switches |
CCS |
Correct Model: 604PM21 Pressure switches |
| Crouzet | Part no: 84134120 Crouzet Solid State Relays, GN Series MOQ = 10pc (BatBuoc) |
| Crouzet | Part no: 84134140 Crouzet Solid State Relays, GN Series MOQ = 10pc (BatBuoc) |
| Crouzet | Part no: 84134140 Crouzet Solid State Relays, GN Series MOQ 10pc |
Crydom |
Code: H12WD4850PG Solid State Relays |
| Crydom | Code: H12WD48125PG Solid State Relays |
| Crydom | Code: H12WD48125PG Solid State Relays |
| Crydom | Code: H12WD48125PG Solid State Relays |
DEMA Engineering/ Foam- IT |
Model: 920N PORTABLE AIR DRIVEN FOAMER ,20 GAL, WHITE (Replace for FI-20N) |
| DINAL | COUPLINGS TYPE GEL 500-S Bore A = 10 mm. Bore B = 14 mm. |
| Dold | Model: MK9151.11 2-450K-OHM AC220-240V Art number: 0044505 LEVEL SENSING |
Dwyer |
Code: CDT-2N40-LCD-RLY SERIES CDT CARBON DIOXIDE/TEMPERATURE TRANSMITTER |
| Dwyer | Code: GSTA-C SERIES GSTA CARBON MONOXIDE/NITROGEN DIOXIDE GAS TRANSMITTER |
| E+H | Code: 5P3B15-AAIBAEAFAAEA1K4AA1+AALA Description: Electromagnetic flowmeter |
| E+H | Code: 5P3B25-AAIBAEAFAAEA1K4AA1+LA Description: Electromagnetic flowmeter |
