SET HT3CIX4P200M12BTX003M572 – Bộ cảm biến quang – Leuze – Song Thành Công

Tên: SET HT3CIX4P200M12BTX003M572 – Bộ cảm biến quang

Model: SET HT3CIX4P200M12BTX003M572

Nhà sản xuất: Leuze

Đại lý phân phối: Song Thành Công

Thông tin sản phẩm:

Xem them thông tin sản phẩm tại đây

Operating range, white 90%0.005 … 0.2 m
Operating range, gray 18%0.01 … 0.16 m
Operating range, black 6%0.015 … 0.13 m
Operating range limit0.005 … 0.2 m
Adjustment range15 … 200 mm
Light sourceLED, Infrared
Electrical data
Protective circuitShort circuit protected, Polarity reversal protection
Performance data
Supply voltage UB10 … 30 V, DC, Incl. residual ripple
Residual ripple0 … 15 %, From UB
Open-circuit current0 … 15 mA
Outputs
Number of digital switching outputs2 Piece(s)
Switching output 1
Switching elementTransistor, PNP
Switching principleLight switching
Switching output 2
Switching elementTransistor, PNP
Switching principleDark switching

Các model sản phẩm:

Bitzer	CDU – Air Cooled (LH) – Ecoline LH265/4GE-20Y (With Pressure Transmitters for application limit monitoring)
BÜRKERT	Code: 00002158 Description: 2/2-way piston control Angle-Seat Valve Type: 2000
BÜRKERT	Code: 00001398 Description: 2/2-way-piston-operated angle-seat valve 2000-A-2-65,0-EE-RG-GM90-B-F*MC13 Type 2000 Control function A – closed by spring force Paths/positions 2 – 2 ways / 2 position Orifice size 65,0 – 65mm (2 1/2″) Seal material EE – PTFE Body material RG – gunmetal Port connection GM90 – G2 1/2 threaded port Actuator version B – PA-actuator, MS-threaded bushing at connection of pilot air Actuator size F – Dm 80mm Special Feature: MC13 – flow above seat Pressure min 0 bar Pressure max 14 bar Pilot pres. min 1,60 bar Pilot pres. max 10 bar KV 77 m3/h T medium min -10 °C T medium max 180 °C T ambient min -10 °C T ambient max 60 °C
BÜRKERT	Code: 00169391 Description: 2/2-way-piston-operated valve 2012-A2-80,0-EE-VA-SA49-C-H-N8-0000*MC13+MC16+NK51 Type 2012 Control function A – closed by spring force Paths/positions 2 – 2 ways / 2 position Orifice size 80,0 – 80mm (3″) Seal material EE – PTFE Body material VA – stainless steel Port connection SA49 – Weld end 88,9 x 2,3 according to ISO 4200, DIN EN ISO 1127, DIN 11866 series B Actuator version C – PA-actuator, VA-threaded bushing at connection of pilot air Actuator size H – Dm 125mm Interface N8 – nipple thread M100 x 2 (standard DN 80) connection of pilot air 0000 – standard pilot air connection resp. integral construction Special Feature: MC13 – flow above seat MC16 – O-ring between cover and actuator housing NK51 – packed seal enclosed Pressure min 0 bar Pressure max 10 bar Pilot pres. min 2 bar Pilot pres. max 7 bar KV 110 m3/h T medium min -10 °C T medium max 180 °C T ambient min -10 °C T ambient max 60 °C
E+E	Code: EE23-T4HS3K5D1/GA6SBL-20SBH120DT2 Humidity/Temperature Sensor
E+H	Code: 8F3B50 – AAIBAEAFAASAD2SAA1 Description: Coriolis flowmeter
E2S	Model: BExL25DFR008AS2A1R Explosion Proof PA Loudspeakers 25W
E2S	Model: BExL25DFV100AS2A1R Explosion Proof PA Loudspeakers 25W
Eurotherm	Part no : 3208/VC/VH/RRRX/R/4XL/S/ENG/ENG/XXXXX/XXX MODEL (3208) Controller UNIT TYPE (VC) Motorised Valve Controller SUPPLY VOLTAGE (VH) 85 – 264 Vac OUTPUT OPTIONS 1 2 3 (RRRX) relay/relay/relay AA RELAY OP4 (R) Relay OPTION BOARD 4XL – 2 Wire RS485 Comms + Logic Input FASCIA COLOUR (S) Silver PRODUCT LANGUAGE (ENG) English MANUAL LANGUAGE (ENG) English Note: TKS932133000 is obsoleted
Eurotherm	Part no : ITOOLS/NONE/USB/////XXXXX Cable and SW for the configuration from PC
Greisinger (GHM)	Code: GMH 3695 Air oxygen measuring device, with datalogger Range: 0.0 … 100.0 % O₂ Vol Temp Range: -5 … +50 °C Air Pressure Range: 300 … 5000 hPa abs, pressure port for tube 6/4; Sensor con’: 6-pin screened Mini-DIN-Socket Datalogger: autom. 8000 data sets, manually 1000 data sets Output: Serial interface, analog output 0 … 1 V scalable
Greisinger (GHM)	Code: GGA370-L04 Atmospheric oxygen sensor, open sensor type O₂ sensor element: GOEL 370, protection gases with higher CO₂ concentrations and O₂ below < 35 vol. % O₂ Measuring range oxygen concentration: 0 … 100 % Vol. O₂, recommended 0.2 … 35 % vol. O₂ (beyond reduced precision) Cable length: 4m Version: With connection for GMH 3600 Serie
