Tên: AMG11 P29 Z0 – 11072315 – Bộ mã hóa vòng quay

Model: AMG11 P29 Z0 – 11072315

Nhà sản xuất: Baumer

Đại lý phân phối: Song Thành Công

Thông tin sản phẩm:

Xem thêm thông tin sản phẩm tại đây



Technical data – electrical ratings

• Voltage supply
• ..30 VDC
• Consumption w/o load
• ≤100 mA (per interface SSI)
• ≤250 mA (per interface bus)
• Initializing time
• ≤ 200 ms after power on

• Interface

• SSI
• Profibus-DPV0
• CANopen®
• DeviceNet
• PROFINET
• Function
• Multiturn
• Transmission rate
• 6 … 12000 kBaud (Profibus)
• 10 … 1000 kBaud (CANopen®)
• 125 … 500 kBaud (DeviceNet)
• 100 MBaud (PROFINET)
• Profile conformity
• Profibus-DPV0
• CANopen® CiA DSP 406 V 3.0
• Device Profile Encoder V 1.0
• Encoder profile PNO 3.162
• Device adress
• Rotary switches in bus cover
• Steps per revolution
• 8192 / 13 bit
• Number of revolutions
• ≤65536 / 16 bit
• Additional outputs
• Square-wave TTL (RS422)
• Square-wave HTL
• Sensing method
• Optical

• Code

• Gray (version SSI)
• Code sequence
• CW default
• Inputs
• SSI clock (version SSI)
• Interference immunity
• EN 61000-6-2
• Emitted interference
• EN 61000-6-3
• Programmable parameters
• Depending on the selected absolute interface
• Diagnostic function
• Position or parameter error
• Status indicator
• DUO-LED integrated in bus cover
• Approval
• CE
• UL approval / E217823
