Tên: dbk+4/Empf/M12/3BEE/M18 – Cảm biến siêu âm

Model: dbk+4/Empf/M12/3BEE/M18

Nhà sản xuất: Microsonic

Đại lý phân phối: Song Thành Công

Thông tin sản phẩm:

Xem thêm thông tin sản phẩm tại đây



working rangepapers with weights of 20 – 600 g/m², Washi, metal-laminated sheets and films up to 0.2 mm thick, self-adhesive films

designcylindrical M12 with a swapped-out ultrasonic transducer

operating modedouble sheet control

particularitiesreceiver for ultrasonic double sheet control
distance between transmitter and receiver can be selected
swapped-out ultrasonic transducer
M12
cable connection

• ultrasonic-specific

• means of measurementpulse operation with amplitude evaluation
• transducer frequency500 kHz
• blind zone5 mm in front of transmitter and receiver
• electrical data
• operating voltage UB20 – 30 V d.c., reverse polarity protection
• voltage ripple± 10 %
• no-load current consumption≤ 50 mA
• type of connection2 m PUR cable, 7 x 0.25 mm2
• transmitter cable1 m PUR cable with M8 initiator plug to the transmitter, 1.2 m PVC cable to the swapped out receiver
• outputs
• output 1double sheet output
  npn: Imax = 200 mA (-UB+2V)
  NOC/NCC adjustable, short-circuit-proof
• output 2missing sheet output
  npn: Imax = 200 mA (-UB+2V)
  NOC/NCC adjustable, short-circuit-proof
• response time< 500 µs in trigger mode, 2.5 ms in free-run mode
• delay prior to availability< 750 ms

• inputs

• description< -UB+6 V: logic 1; > -UB+10 V or control input open: logic 0
• input 1control input
• input 2control input
• input 3control input
• housing
• transmitter/receiver spacing20 – 40 mm; optimal: 20 mm ± 2 mm
• permissible angular deviation± 45° from the perpendicular to the sheet
• materialbrass sleeve, nickel-plated, plastic parts, PBT, PA
• ultrasonic transducerpolyurethane foam, epoxy resin with glass contents
• tightening torque of nutsM18: 15 Nm, M12: 3 Nm
• class of protection to EN 60529IP 65
• operating temperature+5°C to +60°C
• storage temperature-40°C to +85°C
• weight140 g
