FA47/G DRN90L4 – Hộp số – Sew – Song Thành Công
Tên: FA47/G DRN90L4 – Hộp số – Sew
Model: FA47/G DRN90L4
Nhà sản xuất: Sew
Đại lý phân phối: Song Thành Công
Các model sản phẩm khác:
Xem thêm thông tin sản phẩm tại đây
| RAVEL | Model: 1076A Electric motor (5.5hp electric motor) 4kW, 60 Hz Báo giá theo nameplate sales cung cấp Sales confirm thông số kĩ thuật trước khi đặt hàng |
| Rexroth/Aventics | Model: ABZMS-41-1X/0370/D2/DC-K24 PN : R901212594 Float Switch |
| SCHEUCH | Model 1467831 Control unit PM-B+ sfe pmb-plus-ac-ip65 Upgrade ISTZ to PMB+ |
| SCHEUCH | Model 0012174 Differential Pressure Transmitter 0-35 mbar mre ddmu DS3-0-035 |
| Sew | SEW – Typ: FH77/G DRN132L4 Parallel-shaft helical gearmotors F..DRN.. (IE3) As same as 90.7268207807.0002.15 Product data Speed 50Hz [r/min]: 1470 / 255 Speed 60Hz [r/min]: 1775 / 308 Total ratio [i]: 5,76 / infinite Ma max [Nm]: 1,08 Output torque 50Hz [Nm]:345 Output torque 60Hz [Nm]: 285 Service factor SEW-FB: 3,10 / 3,80 Mounting position: M5 Term.box.pos.[°] / cable entry: 180 (L) / position 2 Lubricant / -volume [l]: CLP 220 Miner.Oil / 6,00 Paint coat: Top coat RAL5002 (ultramarine blue) Hollow shaft: 50mm Design: Hollow shaft with shrink disc General access. feature: G with rubber buffer Documentation no. A: 21932840 Parts list: 422661395 Motor power [kW]: 9,2 |
Sew |
SEW – Typ: FA47/G DRN90L4 Parallel-shaft helical gearmotors F..DRN.. (IE3) Information This product is a special design As same as 90.7275545906.0001X16 Product data Speed 50Hz [r/min]: 1461 / 50 Speed 60Hz [r/min]: 1767 / 60 Total ratio [i]: 29,32 / infinite Ma max [Nm]: 400 Output torque 50Hz [Nm]: 285 Output torque 60Hz [Nm]: 240 Service factor SEW-FB: 1,40 / 1,70 Mounting position: M6 Term.box.pos.[°] / cable entry: 90 (B) /normal Lubricant / -volume [l]: CLP 220 Miner.Oil / 1,70 Paint coat: Top coat RAL5002 (ultramarine blue) Hollow shaft: 35mm Design: Hollow shaft Safety cover: None General access. feature: G with rubber buffer Documentation no. A: 21932840 Parts list: 422561395 Motor power [kW]: 1,5 |
| Sew | SEW – Typ: FA57/G DRN100L4/TF Parallel-shaft helical gearmotors F..DRN.. (IE3) As same as 90.7417198503.0001.17 Product data Speed 50Hz [r/min]: 1459 / 48 Speed 60Hz [r/min]: 1765 / 59 Total ratio [i]: 30,15 / infinite Ma max [Nm]: 590 Output torque 50Hz [Nm]: 435 Output torque 60Hz [Nm]: 360 Service factor SEW-FB: 1,35 / 1,65 Mounting position: M5 Term.box.pos.[°] / cable entry: 90 (B) / position 2 Lubricant / -volume [l]: CLP 220 Miner.Oil / 2,35 Paint coat: Top coat RAL5002 (ultramarineblue) Hollow shaft: 40mm Design: Hollow shaft Safety cover: None General access. feature: G with rubber buffer Documentation no. A: 21932840 Parts list: 422511099 Motor power [kW]: 2,2 |
Sew |
SEW – Typ: FH67/G DRN90L4 Parallel-shaft helical gearmotors F..DRN.. (IE3) As same as 90.7414434310.0001.17 Product data Speed 50Hz [r/min]: 1461 / 24 Speed 60Hz [r/min]: 1767 / 29 Total ratio [i]: 61,07 / infinite Ma max [Nm]: 820 Output torque 50Hz [Nm]: 600 Output torque 60Hz [Nm]: 495 Service factor SEW-FB: 1,35 / 1,65 Mounting position: M1 Term.box.pos.[°] / cable entry: 180 (L) / normal Lubricant / -volume [l]: CLP 220 Miner.Oil / 2,70 Paint coat: Top coat RAL5002 (ultramarineblue) Hollow shaft: 40mm Design: Hollow shaft with shrink disc General access. feature: G with rubber buffer Documentation no. A: 21932840 Parts list: 422611495 Motor power [kW]: 1.5 |
| VAHLE | Code: 0262018/00 Description: VM-SCHV13 / 63-200A-KBHS / MKHS / MKLS SCREW CONNECTOR FOR 13 MM COPPER (63-200 A MKHS) (63-160 A KBHS) (ALSO SUITABLE FOR THE RELEASED 40A VERSION) |
| Vaisala | Code: 19729HM LiCl Salt with Certificate |
Vaisala |
Code: 19731HM NaCl Salt with Certificate |
| Vaisala | Code: 19729HM LiCl Salt with Certificate |
| Vaisala | Code: 19731HM NaCl Salt with Certificate |
| Vmeca | Model: VP20V-01-F1-C Digital Vacuum Switch Sensing |
Wika |
Pressure Transmitter for general applications Brand: WIKA Model: S-11 WITH FLUSH DIAPHRAGM Measuring range: 0…10 bar Output signal: 4…20Ma, 2-wire Process Connection: G ½ B, flush diaphragm with O-ring Power supply: 10…30 V DC. Plz recheck before order |
| Wika | Bourdon Tube Pressure Gauges, Stainless Steel Series Model: 233.50 Specifications according to data sheet: PM 02.02 Measuring system: stainless steel Case filling: with Nominal size: 100 mm Scale range: 0…16 bar Process connection: 1/2 NPT Connector location: lower mount Window: laminated safety glass Pointer: adjustable pointer Accuracy class: class 1.0 Overpressure safe: standard Case material: Stainless steel 316TI Case surface: bare Material pressure element: Measuring System 316L Case filling fluid: glycerine Ingress protection: IP 65 Permissible medium emperature: + 100 °C Permissible ambient temperature: -20 … +60 °C Movement: stainless steel Packaging: single packing Pressure Gauge Standard: International (standard Europe) ** Offer 233.50 as per stated in enquiry. Take note this is not solid front case type. |
Wika |
Bourdon Tube Pressure Gauges, Stainless Steel Series Model: 232.50 Specifications according to data sheet: PM 02.02 Measuring system: stainless steel Case filling: without Nominal size: 100 mm Scale range: 0…16 bar Process connection: 1/2 NPT Connector location: lower mount Window: laminated safety glass Pointer: adjustable pointer Accuracy class: class 1.0 Overpressure safe: standard Case material: Stainless steel 1.4301 Case surface: bare Material pressure element: Measuring System 316L Case filling fluid: prepared for filling Ingress protection: IP 65 Permissible medium temperature: + 100 °C Permissible ambient temperature: -20 … +60 °C Movement: stainless steel Packaging: single packing Pressure Gauge Standard: International (standard Europe) |
| Wika | Bourdon Tube Pressure Gauges, Stainless Steel Series Model: 233.50 Specifications according to data sheet: PM 02.02 Measuring system: stainless steel Case filling: with Nominal size: 100 mm Scale range: 0…10 barg Process connection: 1/2 NPT Connector location: lower mount Window: laminated safety glass Pointer: adjustable pointer Accuracy class: class 1.0 Overpressure safe: standard Case material: Stainless steel 1.4301 Case surface: bare Material pressure element: Measuring System 316L Case filling fluid: glycerine Ingress protection: IP 65 Permissible medium temperature: + 100 °C Permissible ambient temperature: -20 … +60 °C Movement: stainless steel Packaging: single packing Pressure Gauge Standard: International (standard Europe) |
Wika |
Bourdon Tube Pressure Gauges, Safety Pattern Series EN 837-1 Model: 233.30 Specifications according to data sheet: PM 02.04 Measuring system: stainless steel Case filling: with Nominal size: 100 mm Measuring range: gauge pressure range Scale range: 0…10 bar Process connection: 1/2 NPT Connector location: lower mount Window: laminated safety glass Pointer: standard pointer Accuracy class: class 1.0 Overpressure safe: standard Case material: Stainless steel 1.4301 Case surface: bare Material pressure element: Measuring System 316L Case filling fluid: glycerine Ingress protection: IP 65 Permissible medium temperature: + 100 °C Permissible ambient temperature: -20 … +60 °C Movement: stainless steel Packaging: single packing Pressure Gauge Standard: International (standard Europe) Manufacturer logo: *WIKA* with Serial number Permissible ambient temperature: -20 … +60 °C |
| Wika | Bourdon Tube Pressure Gauges, Stainless Steel Series Model: 233.55 Measuring system: stainless steel 316 Accuracy class: 2/1/2% of span ASME B40.100 Grade A Nominal size: 2 ½” (63mm) Pressure Range: 0 … 160 psi Case filling: glycerine oil Process connection: 1/4″ NPT male, lower back mount Mounting: front flange panel mounting Window: laminated safety glass Pointer: black, aluminium Ingress protection: IP 65 |
NGUYỄN VĂN TÚ
PHONE: 035 964 3939 (ZALO) – 0914 141 944
EMAIL: vantu@songthanhcong.com
Cung cấp sản phẩm chính hãng, giá cạnh tranh !
