HT3CI X/4P-200-M12 – Cảm biến khuếch tán – Leuze

HT3CI X/4P-200-M12 – Cảm biến khuếch tán – Leuze – Song Thành Công



Tên: HT3CI.X/4P-200-M12 – Cảm biến khuếch tán

Model: HT3CI.X/4P-200-M12

Nhà sản xuất : Leuze

Đại lý phân phối: Song Thành Công



Thông tin sản phẩm:

Xem thêm thông tin sản phẩm tại đây



• Series3C
• Operating principleDiffuse reflection principle with background suppression
• ApplicationDetection of labels on bottles
• Optical data
• Operating range, white 90%0.005 … 0.2 m
• Operating range, gray 18%0.01 … 0.16 m
• Operating range, black 6%0.015 … 0.13 m
• Operating range limit0.005 … 0.2 m
• Adjustment range15 … 200 mm
• Light sourceLED, Infrared
• Electrical data
• Protective circuitPolarity reversal protection, Short circuit protected
• Performance data
• Supply voltage UB10 … 30 V, DC, Incl. residual ripple
• Residual ripple0 … 15 %, From UB
• Open-circuit current0 … 15 mA

Các model sản phẩm khác:

Leuze	Code: PRK18B.XTT3/4P-M12 Polarized retro-reflective photoelectric sensor, Detection of highly transparent bottles, films and glass panes, Autocollimation, Tracking, Range limit 0…3.6m, LED, Red, 10-30VDC, PNP Light + PNP Dark switching, M12 4pin connector, IP69K, Teach button
Leuze	Code: PRK18B.XT2/4P-M12 Polarized retro-reflective photoelectric sensor, Detection of highly transparent bottles, films and glass panes, Autocollimation, Operating range limit 0…4.8m, LED, Red, 10-30VDC, PNP Light switching + PNP Dark switching, M12 4pin connector, IP67/69K
Leuze	Code: HT3CI.X/4P-200-M12 Diffuse sensor with background suppression, Detection of labels on bottles, range limit 0.005…0.2m, LED, Infrared, 10-30VDC, PNP Light switching + PNP Dark switching, 200mm Cable with M12 4pin connector, Multiturn potentiometer, -40…60°C, IP67/69K Note: Alternatives to RK 72/4-200 L.2 – no longer avail
Leuze	Code: SET HT3CIX4P200M12BTX003M572 Diffuse sensor with background suppression set, Detection of labels on bottles, range limit 0.005…0.2m, LED, Infrared, 10-30VDC, PNP Light + PNP Dark switching, 200mm Cable with M12 4pin connector, Multiturn potentiometer, -40…60°C, IP67/69K, Note: Alternatives to RK 72/4-200 L.2 – no longer avail
EBMPAPST	Model : A2D300-AD20-49 Axial Fan
Delta Ohm	HD2303.0 Anemometer-Thermometer for air speed measurement
Delta Ohm	AP472S1 Vane probe with K type thermocouple
Delta Ohm	AP472S2 Vane probe ∅ 60 mm with handle ISO 17025 Calibration Certificate is included.
