OXY 3690 MP – Air Oxygen Measuring transducer – Greisinger

OXY 3690 MP – Air Oxygen Measuring transducer – Greisinger – Song Thành Công

Tên: Air Oxygen Measuring transducer

Model: OXY 3690 MP

Nhà sản xuất: Greisinger

Xuất xứ: Germany

Nhà phân phối: Song Thành Công



Thông tin sản phẩm:

Thông tin chi tiết sản phẩm tại đây



Dim	(L x W x H) 55 x 82 x 80 mm
Height	80mm
Length	55mm
Width	82mm
Reading range	0 – 100 %
IP rating	IP65
Features	External sensor, Oxygen sensor, Thermometer
Unit of measurement	Oxygen, Temperature
Reading range (max.)	100%
Reading range (min.)	0%
Resolution	0.1%
Cable length	130cm
Weight	360g
Product type	Oxygen detector



Compare in category

• Measuring range temperature: -20 to +50 °C
• Output signal: 4 – 20 mA

Air-oxygen transducer Oxy 3690

• Air-oxygen transducer including sensor. Suitable for measurements on the atmosphere, as well as in systems without or with low over and under pressure.

  This text is machine translated.

Highlights & Details

• Air pressure compensation: 500 to 2000 hPa
• Includes electrode with integrated temperature sensor

Facts

• High-quality oxygen measuring sensor
• Operating pressure: 500 to 2000 hPa (static)

Delivery

• Measuring transducer
• Oxygen sensor
• User manual
