P30U 101100E1 – Bộ chuyển đổi tín hiệu – Lumel

P30U 101100E1 – Bộ chuyển đổi tín hiệu – Lumel – Song Thành Công

Tên: P30U 101100E1 – Bộ chuyển đổi tín hiệu – Lumel

Model: P30U 101100E1

Nhà sản xuất: Lumel

Xuất xứ: Poland

P30U 101100E1 – Bộ chuyển đổi tín hiệu

nput: programmable
thermocouples, resistance thermometers,
0…4/20 mA, +/- 20mA
-5…20mV, +/- 75mV; +/-200mV
400, 2000, 5500 ohm
RS485 Master or Slave
output: programmable
analog (current or voltage)
1 or 2 x relays
digital RS-485
display: LCD 2 x 8 characters with backlight,
supply: 85..253 V a.c./d.c. or 20…40 V a.c./20…60 V d.c.
conversion of the measured value into any output signal on the basis of the individual liner characteristics,
conversion of the measured value by means of one of five implemented mathematical functions,
conversion of the measured value on the basis of 21-point individual characteristics,
additional 24V DC 30mA power supply switched on/off like an alarm (option)
indication of exceeding the alarm values,
programmable alarm and analogue outputs with a reaction to the selected input value (main input or RTC clock),
real time clock with a clock power supply backup function in case of a transducer power supply loss,
recording the signal input in programmed time periods in the internal memory and on SD/SDHC card (option),
internal memory with the capacity of 534336 records,
automatic decimal point setting,
preview of configured parameters,
access to parameters locked by a password,
programming the measurement averaging time.

Các model sản phẩm:

Lumel	Code: P30U 101100E1 Progr. transducer, temper., dc input 1:output 0/4-20mA, 0:no SD slot, 1:second relay 1:supply 85-253Vac/dc 00:standard version E:English version 1:QI certificate
Para-Ent	Model: TPP3-250 Digital Power Regulator Three phase, 380V, 250A
RainWise	Model: PVMET 150 Weather station SKU: 800-0092
RainWise/ Eko	Model: EKO MS-80 Pyranometer SKU: 211-0110
Sipos	Model : 2SA7321-0CE00-4BB4-ZB49 Electric Rotary Actuator
Solo Tester	Code: SOLO 822-101 Code: Description: Smoke & Cordless Heat Detector Test Set to : 6 METRES Includes: 1 x Solo 100 Fibreglass Telescopic Extension Pole 4.5 metres 1 x Solo 200 Universal Removal Tool 1 x Solo 330 Aerosol Smoke Dispenser 1 x Solo 461 Cordless Heat Detector; Test Set 1 x Solo 610 Protective Carrying / Storage Bag
Unipulse	Model: F490A Indicator
Unipulse	Model: RSCC-50KG Load Cell
Unipulse	Model: RSCC-500KG Load Cell
Unipulse	Model: RSCC-5T Load Cell
Unitronics	Code: JZ20-J-R10 JAZZ-J ,Disp2X16,6IN 4Rout,USB
Unitronics	Code: JZ20-J-R16 JAZZ-J ,Disp2X16,10/6IO,AN,USB
Vaisala	Code: GMD20 CO2 Transmitter, 0-2000 ppm, Duct Model
Vaisala	Code: HMP360 4E2A3A3 Humidity and Temperature Probe for HMT360 HMP364 for pressurized processes Hmp364 2m Cable Humicap 180l2 Reserved for future us Sintered Filter AISI 316L HM47280 No Installation Kit Ex Certification IECEx/VTT
