Tên:  SFM-B02 – Bộ giám sát an toàn

Model: SFM-B02

Nhà sản xuất:  Euchner

Đại lý phân phối: Song Thành Công

Thông tin sản phẩm:
Xem thêm thông tin sản phẩm tại đây

Weight
Net	0,45 kg
Ambient temperature	-20 … +60 °C
Degree of protection	IP20
Mounting method	Mounting rail 35mm according to DIN EN 6715 TH35
Connection	Connection terminals
	Safety contacts 1.14, 1.24, 2.14, 2.24
Number of safety contacts	2
	Auxiliary contact terminals: L/+/1.Y1, L/+/2.Y1
Number of monitoring contacts	2
	Terminals for the start buttons: 1.Y2, 2.Y2
Number of inputs	2
ASi voltage		18,5 … 31,6 V
ASi operating current		max.45 mA
Operating voltage DC		24 V DC -15% … +15%
Rated operating current Ie		200 mA
Thermal rated current Ith		3 A
Utilization category acc. to EN 60947-5-1
AC-15		3A 230V
DC-13		1A 24V
