MMT330 8W0F101RCAM110B02ENBAA1 – Cảm biến nhiệt độ – Vaisala

NGUYỄN VĂN TÚ

PHONE: 035 964 3939 (ZALO) – 0914 141 944

EMAIL: vantu@songthanhcong.com

Cung cấp sản phẩm chính hãng, giá cạnh tranh !

MMT330 8W0F101RCAM110B02ENBAA1 – Cảm biến nhiệt độ – Vaisala – Song Thành Công

Tên: MMT330 8W0F101RCAM110B02ENBAA1 – Cảm biến nhiệt độ

Model: MMT330 8W0F101RCAM110B02ENBAA1

Nhà sản xuất: Vaisala

Đại lý phân phối: Song Thành Công

Vaisala HUMICAP® Moisture and Temperature Transmitter MMT330 series enables fast and reliable detection of moisture in oil in central lubrication systems, hydraulic systems and power transformers. The series is also compliant with DNV GL 2.4 type approval (Class B).
Looking for MMT330 performance with interchangeable probes and a transmitter supporting two probes
There are three probe types to enable various types of installations:
MMT332 for high pressure installations, see also MMP8
MMT337 for tight spaces with a thread connection, see also MMP8
MMT338 for pipeline installations, see also MMP8
Features
Continuous online measurement of moisture in oil
Installation through ball valve. No need to shut down the process.
Proven Vaisala HUMICAP® sensor, used for over 15 years in oil application
Easy field calibration and maintenance – compatible with Vaisala HUMICAP® Hand-Held Moisture Meter for Oil MM70
Online, real-time detection of moisture in oil without sampling.
Integrated data logging, with over four years of measurement history
Traceable calibration to national standards (certificate included)
Multi-year Calibration Care agreement option to ensure as-good-as new accuracy for years

MTS Sensor	Replace Code: RH5MA0170M01D701S1011G8 Temposonics R-Series Note: RHM0170MD701S1G8100 is obsoleted Recheck delivery time before order
MTS Sensor	Code: EP01400MD341V03 Temposonics E-Series Recheck delivery time before order
PORA	Model: PRC-0.6A4 POWDER CLUTCH
PORA	Model: PRC-0.3A4 POWDER CLUTCH
Proface	Model : PFXGP4501TAD Màn hình
SMC	Model: CRB1BW63-180S Rotary Actuator
Vaisala	MMT330 8W0F101RCAM110B02ENBAA1 Oil Moisture And Temperature Transmitter Transmitter Type: Code 8 Probe Cable Length: Probe 5m Reserved 1: No Temperature Probe Measurement Parameters: Code aw+T+ppm With Display Power Supply: Standard (10…35V,24VAC) Analog Output: 4…20mA Analog Output Parameter and Scaling for CH1: ppm 0..500 Analog Output Parameter and Scaling for CH2: Channel 2 T (Range See Below) No Analog Output Parameter & Scaling for CH3 Analog Output Range for Temperature: 0…+120C Metric Units Additional Feature: Relay Module No Additional feature 2 Interface Cable Connection: Cond Uit Fitting NPT 1/2″ No Transmitter Housing Installation Humidity Sensor: Humicap 180L2 Sensor Chemically resistant Sensor Protection: Stainless Steel Filter Hole diam. 2mm HF Probe Installation Accessories: Fitting Body NPT1/2 with No Leak Srew User’s Guide MMT330 English No PC Accessories No Calibration Contract ISO9001 Calibration Reserved 2: No Maintenance Contract
Westermo	Code: DDW-120 3621-0110 SP-SAT-21-0347 Ethernet SHDSL Extender
